24-Port Keystone IP Panel

24-port Keystone IP panel designed specifically for broadcast stations and repeaters. A wide variety of attachments allow you to build your ideal IP system.

Key Features and Benefits

  • Keystone couplers can be freely positioned relative to the 24-channel patchpanel
Note:
Compatibility is not guaranteed for all keystone couplers made by other manufacturers. Please check compatibility before use.
  • Tech Data
  • Downloads

24-Port Keystone IP Patchbays

Type Panel Size Model Spec
  • Color : BLK

1RU 24KRJ-6AJJ 24 × RJ45 Unshielded Cat6A Couplers
  • Color : BLK

1RU 24KRJS-6AJJ 24 × RJ45 Shielded Cat6A Couplers

24-Port Keystone IP Panel

Type Panel Size Model Spec
  • Color : BLK

1RU K24S-1U-BLK 24holes Unshielded/Shielded Unloaded Panel

Key Features and Benefits

  • Unified design
  • Robust construction
  • 8.5 × 426mm free designation area
  • Can be recessed 25mm.(*1)
Note :
(*1) Can be recessed 50/75 mm by changing the mounting brackets to M-MA1U02A.

Accessories

Type Model Description
M-KB01 type M-KB01 Cable Tie Bar
SG002-T36 type SG002-T36 Grounding Cable 0.2m
SG032-T3 type SG032-T30 Grounding Cable 3.2m

Key Features and Benefits

  • Grounding cables are ideal for shielded Cat6A panels and a rack.
  • 4krj-6ajj drawing

    [ M-KB01 Example ]

  • SG032-T30 Accessories

    [ SG032-T30 Accessories M6 1pc ]

Unique 7 Points

  • Unified Design

    Unified Design

    Canare IP panels are similar in appearance to our video patchbays.

  • Mobile Truck Ready

    Mobile Truck Ready

    Tested through heavy - duty vibration for live production applications.

  • Non - Splitted Designation Strip

    Non - Splitted Designation Strip

    8.5 × 426mm free designation area to write on.

  • Wide range of IP interface

    Wide range of IP interface

    Choose from 12 types of IP couplers.

  • No Special Tool

    No Special Tool

    For interchanging couplers, just use a flathead screwdriver.

  • Depth Adjustable Front Mount

    Depth Adjustable Front Mount

    In case of space efficiency, patching surface can be recessed 25mm, 50mm or 75mm deeper.

  • Cable Tie Bar

    Cable Tie Bar

    Optional cable tie bar will help optimize wiring support.

  • 4krj-6ajj drawing

    24KRJ-6AJJ / 24KRJS-6AJJ / K24S-1U-BLK
    Drawing

Keystone IP Couplers

Spec Type Model Description Compatible Standards
RJ RJUJ-J6A RJ45 Modular Relay Adapter IEC 60603-7
ANSI/TIA568-C.2
RJSJ-J6A RJ45 Modular Relay Adapter (shield)
DLC FKDLJ-JS DLC Adapter Module (SM) JIS C 5964-20
IEC 61754-20
IEC 60603-7
FKDLJ-JM DLC Adapter Module (MM)
FKDLJ-JS-S DLC Adapter Module with shutters (SM)
FKDLJ-JM-S DLC Adapter Module with shutters (MM)
SC FKSJ-JS SC Adapter Module with shutters (SM) JIS C 5964-4
IEC 61754-4
IEC 60603-7
FKSJ-JM SC Adapter Module with shutters (MM)
FKSJ-JS-S SC Adapter Module with shutters (SM)
FKSJ-JM-S SC Adapter Module with shutters (MM)
MPO FKMPJ-JM THUM FKMPJ-JM MPO Adapter Modul (MM) JIS C 5964-7
IEC 61754-7
IEC 60603-7
- BP-K(10) Blank panel (10 per pack) -

Key Features and Benefits

  • Compatible with Keystone Panels.
  • A wide array of different connection options.
  • Fast and easy to install.
  • Blank Plate : Protects unused ports from dirt and dust.
  • RJUJ-J6A draw

    RJUJ-J6A

  • RJSJ-J6A draw

    RJSJ-J6A

  • FKDLJ-J* draw

    FKDLJ-J*

  • FKDLJ-J*-S draw

    FKDLJ-J*-S

  • FKSJ-J* draw

    FKSJ-J*

  • FKSJ-J*-S draw

    FKSJ-J*-S

  • FKMPJ-JM draw

    FKMPJ-JM

DLC Loopback

Type Model Description
FKDLP-SUL DLC Loopback(U-LINK)(SM)

Key Features and Benefits

  • Loop signal for maintenance
  • Built - in dust cap holder
  • FKDLP-SUL draw

    FKDLP-SUL
